BIDI PON SFP Optical Transceiver 2.5Gb/s Class C+ 20Km Single 3.3V Power Supply

BIDI PON SFP Optical Transceiver 2.5Gb/s Class C+ 20Km Single 3.3V Power Supply

  • BIDI PON SFP Optical Transceiver 2.5Gb/s Class C+ 20Km Single 3.3V Power Supply
  • BIDI PON SFP Optical Transceiver 2.5Gb/s Class C+ 20Km Single 3.3V Power Supply
BIDI PON SFP Optical Transceiver 2.5Gb/s Class C+ 20Km Single 3.3V Power Supply
Product Details:
Place of Origin: China
Brand Name: Superxon
Certification: TUV/ FCC/ UL/ROHS/FDA
Model Number: SOGQ4321-PSGB
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Get Latest Price
Packaging Details: Plastic Tray
Delivery Time: ASAP
Payment Terms: T/T
Supply Ability: 10,000 pcs/ month
Contact Now
Detailed Product Description
Product Name: SFP Module Wavelenth: 1490nmTX / 1310nmRX
Rare: 2.5Gb/s TX / 1.25Gb/s RX Reach: CLASS C+
Warrenty: 2 Years Compatible: Full Compatible
High Light:

fiber optical transceiver

,

fibre channel sfp

SFP PON Transceiver OLT BIDI 2.5Gb/s Class C+ 20Km SC / UPC RECE

Specifications:

P/N

SOGQ4321-PSGB

Data rate:

2.5Gb/s

Distance

CLASS B+

Wavelength

1490nm T/1310nm R

Transmitter

DFB

Receiver

APD

DDM

Yes

Connector

SC

Operating Temperature

-0~70℃

Voltage Supply

3.3V

Brand

Superxon

Certification

TUV/FCC/UL/ROHS/ FDA/CDRH

FEATURES

Single fiber bi-directional data links asymmetric TX 2488Mbps/RX1244Mbps application
1490nm continuous-mode DFB laser transmitter and 1310nm burst-mode APD-TIA receiver
Small Form Factor Pluggable package with SC/UPC Connector
Support Class C+ 17~32dB attenuation range application (With FEC)
Reset burst-mode receiver design support more than 15dB dynamic range
0 to 70°C operating case temperature
Single 3.3V power supply
Digital diagnostic monitoring interface
Digital burst RSSI function to monitor the input optical power level
LVPECL compatible data input/output interface
LVTTL transmitter disable control
LVTTL transmitter laser fault alarm
LVTTL receiver Signal Detect (SD) indication response within 50ns.
Low EMI and excellent ESD protection
Class I laser safety standard IEC-60825 compliant
RoHS-6 compliance



APPLICATIONS



Gigabit-capable Passive Optical Networks (GPON) Class C+ 20Km 17~32dB attenuation range



STANDARDS



Complies with SFP Multi-Source Agreement (MSA) SFF-8074i
Complies with SFF-8472 Rev 9.5
Complies with ITU-T G.984.2 Amendment 2
Complies with FCC 47 CFR Part 15, Class B
Complies with FDA 21 CFR 1040.10 and 1040.11



Competitive Advantage:



1 Excellent quality with 2 years warranty

2 Keep stock , Fast delivery

3 Competitive pricing

4 OEM/ODM Customized label



BIDI PON SFP Optical Transceiver 2.5Gb/s Class C+ 20Km Single 3.3V Power Supply 0



Other Types:



PN Media Type λ(nm) LD/PD Rate(Gb/s) Reach Temp Connector DDMI
SOGP4321-PSGB SMF 1490T / 1310R DFB/APD 2.488T / 1.244R Class B+ C , I SC Y
SOGQ4321-PSGB SMF 1490T / 1310R DFB/APD 2.488T / 1.244R Class C+ C , I SC Y
SOGP3412-FAGA/B SMF 1310T / 1490R DFB/APD 1.244T / 2.488R Class B+ C , I SC Y
SOGP3412-FUGA/B SMF 1310T / 1490R DFB/APD 1.244T / 2.488R Class B+ C , I SC Y
SOGP3412-FSGA/B SMF 1310T / 1490R DFB/APD 1.244T / 2.488R Class B+ C , I SC Y
SOGP3412-PSGA/B SMF 1310T / 1490R DFB/APD 1.244T / 2.488R Class B+ C , I SC Y
SOGP3412-PSGM SMF 1310T / 1490R DFB/APD 1.244T / 2.488R Class B+ C , I SC Y



BIDI PON SFP Optical Transceiver 2.5Gb/s Class C+ 20Km Single 3.3V Power Supply 1





Why choose Superxon:



Sichuan Superxon Information Technology Co.Ltd.is a leading supplier which provide the optical transceiver modules with the high performance price ratio and headquartered in Chengdu, China, founded in 2007.



   Superxon focuses on R&D, Manufacture, Operation and Service. Superxon provide the optical transceiver modules as their major business, such as OSA, CPE and XO. Superxon provides products and innovations technology in TELECOM, DATACOM, FTTX, Enterprise, Storage, Metro and CWDM/DWDM optical networks, and supports the data rates from 100Mb/s to 40Gb/s, the transmission distance from 300m to 120Km. These products are sold all around the world, such as Huawei,ZTE, Fiberhome, ALU, UTstarcom, Mitsubishi Electric, Sumitomo, Dasan, Ubiqoss, etc. All the products have the TUV,FCC,FDA/CDRH and UL .etc international certification.



   Superxon will continue depending on technology edge and adhering to the major direction to achieve harmonious win-win with customers and suppliers. Superxon aims to meet customers’ needs, growing with customers, and creates a good development platform to employees.
