Product Details:
Place of Origin: China
Brand Name: Sunlit
Certification: CE
Model Number: SMB Series
Payment & Shipping Terms:
Minimum Order Quantity: 1-99
Packaging Details: Gift box/ White box
Delivery Time: 1-15days after payment
Payment Terms: FOB Shenzhen
Supply Ability: 50000/month
Contact Now
Detailed Product Description
Outdoor Detection: 20/40/60/80m Beams For Option: 2/4/6/8/10/12 Beams
Voltage: DC 13.8-24V AC 11-18V Alarm Output: CN CO Contact Capacitor
Highlight:

photoelectric beam sensor

Monitored Intrusion Alarm System For Terrace , residential alarm systems

Monitored Intrusion Alarm System For Terrace , residential alarm systems 0

Detailed Product Description





4 Frequencies Mini Beams Fence Barrier, Monitored Alarm Systems For Terrace, Windows


Features:
* 4 frequencies for option to offer an effective solution to mutual interference among each group of barriers.
* Bi-directional mutual-transmission operation way to avoid sunshine interference.
* AGC control circuit to confirm its normal operation in very severe environments such as wind, frost, rain, snow and fog etc.
* Hint of aiming status, more convenient and quick installation.
* Multi layers technical process on anti-thundering, water-proof and static-immunity.
* Qualified aluminum alloy housing, special and elegant appearance design.
* 360°for horizontal rotation, convenient for installation and usage.
* Military and industrial grade transmission, receiver works with non-spherical lens to get more stable operation and longer distance.
* Multi height and operation distances for option.
* Intelligent pet-immunity technology.
* It is fit for installation in terrace, windows, alley, warehouse, villa, military area and governmental offices etc.



Monitored Intrusion Alarm System For Terrace , residential alarm systems 1



Parameter:



Items

SMB-420 SMB-620

SMB-820 SMB-1220

SMB-440 SMB-640

SMB-840 SMB-1240

SMB-460 SMB-660

SMB-860 SMB-1260
Distance 20/40/60m
Voltage DC 13.8-24V AC 11-18V
Alarm Output CN CO Contact capacitor AC, DC 30V/0.5mA
Operation Temperature -25℃～+60℃
Operation Humidity 5%---95%
Optical Axis Adjustment H: ±90° V: ±2°
Tamper output Normal close (NC) touching capability AV/DC 24V/0.5mA
