Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply

Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply

  • Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply
  • Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply
  • Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply
  • Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply
  • Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply
Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply
Product Details:
Place of Origin: Shenzhen China
Brand Name: OEM/ODM
Certification: CE
Model Number: PMR2000S,PMR3000S
Payment & Shipping Terms:
Minimum Order Quantity: 50PCS
Price: Negotiable
Packaging Details: 640*570 *230 mm(D*W*H),1pcs/1ctn
Delivery Time: 3 weeks after down payment
Payment Terms: TT or LC
Supply Ability: 3000pcs/month
Warranty: 18months after shipment, 10 years spare parts support
Price term: FOB SHENZHEN
Contact Now
Detailed Product Description
High Light:

uninterruptible power system

,

rack mounted ups


Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply



Quick Detail:



1)Smart RS232(USB,SNMP OPTIONAL)

2)Rated voltage:  220v/230v/240Vac or 110/120/120Vac

3)Self-diagnosis system at ups start



Perfect Application:
Computer center, network center, communication system
 automatic control system data center or other critical systems.

Main Features:
High frequency and online double conversion
Wide input voltage (110-285Vac or 65-148Vac)
Self-diagnosis system at ups start
Digital control technoloy and advanced PFC
Output PF0.8,(0.9 optional)
Lighting and surge protection 1050j
Generator compatible
Smart RS232(USB,SNMP OPTIONAL)
EMI/RFI noise filter
Overview
With true double-conversion design, PowerMaster series provides powerful and overall protection to your sensitive devices. It can accept wider input voltage for harsh environment. It's perfect protection for your precisous servers and workstaiosn.
Specifications
Model PMR02S PM3000S
Capacity 2KVA/1.6kW 3KVA/2.4kW
Phase Single
Input voltage
Input PF above 0.98
THDi less than 5%
Rated voltage 220v/230v/240Vac or 110/120/120Vac
Input voltage range Low line  transfer:176 VAC ± 3% @ 100% load
130 VAC ± 3% @ 50% load
85-148Vac( for 110/120/127Vac)
Low line comback:188VAC ± 3% @ 100% load
142 VAC ± 3% @ 50% load;
100vac±5Vac(110/120/127Vac)
High Line Transfer:286 ± 3%148Vac ± 3%(for 110/120/120vac);
High Line Come Back:271 ± 3%;
145Vac±5Vac(110/120/127Vac)
Rated frequency 50/60hz(auto sensing)
Input frequency range 46~54 Hz ◎ 50 Hz / 56~64 Hz ◎ 60 Hz
By-pass input
Input voltage range 170VAC—270VAC±5V
Frequency following range 46~54 Hz ◎ 50 Hz / 56~64 Hz ◎ 60 Hz
Recharge battery
Floating charge voltage 84VDC
Recharging current 1A(Rack batt.case)
Battery
Battery quantity 6PCS*12Vdc*7AH 6PCS*12Vdc*9AH
AC output
Power factor 0.8
Phase single
Rated voltage 220v/230v/240v+/-1.5%
Frequency 50/60hz
Frequency stability ±0.1HZ(battery inverter)
Voltage stability within±1.5%( Static)
  Crest factor 3:1(max)
Wave distortion Linear load less 3%,Non-linear load less 5%;
Over load ability 30s when overload is 108%~150%;200ms above 150%;
Transfer time 0ms
Alarm
AC abnomal Alarm every 4 seconds
Battery low voltage Keep alarm every 1 second
Overload Keep alarm every 0.5 second
Failure Keep alarm
System
Efficiency above 87%
Display LCD+LED
Protection Output short circuit , Overload , Output low voltage, Battery low voltage,                 Over-temperature etc.
 over-voltage protection,over-tempreture protection for charger PCB,and soft-start function for each function module.
Infterface RS232(USB OPTIONAL)
Working Temp. 0~40℃
Relative humidity 0~90%( No coagulation)
Cooling Intelligent speed-control Fan
Input & output  Socket(Optional)
Others
Surge protection IEC60664—1 Graded protection
EMI EN 55022  Grade A
ESD IEC 1000-4-2:Grade 3
EFT IEC 1000-4-4:Grade 3
RS IEC 1000-4-3:Grade 3
SURGE IEC 1000-4-5:Grade 3
Physical
Weight(N/G)kgs 25.0/28.0 28.0/31.0
Unit Size 510* 440 *132 mm(D*W*H)
Packing Size 640*570 *230 mm(D*W*H)

 Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply 0

Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply 1
